The Viktor AS/RS (Automated Storage and Retrieval System) Racking System is a modular, high-density storage solution engineered for industrial warehouses requiring precision, scalability, and operational efficiency. Combining heavy-duty racking structures with automated material handling technologies, this system supports fully autonomous workflows, minimizing manual intervention while maximizing vertical storage utilization. Suitable for logistics centers, manufacturing facilities, and cold storage environments.
| Parameter | Custom Configurations |
| Maximum Height | Up to 25 m (site-specific)3,000 kg (heavy industrial) |
| Unit Load Capacity | 3,000 kg (heavy industrial) |
| Travel Speed | 200 m/min (high-speed models) |
| Lifting Speed | 35 m/min |
| Control System | IoT/Cloud-Based Fleet Management |
| Operating Temperature | Custom (-40°C to +80°C) |
| Compliance | Client-Specific Certifications |
Structural Design
Material: High-tensile steel (S355JR or Q235B) with electrostatic powder coating (60–80 μm).
Safety: Laser-guided collision avoidance, seismic reinforcement (up to 0.5g seismic zones), and UL-listed electrical components.
Automation Integration
Stacker Cranes: Dual-mast or single-mast configurations with servo-driven positioning (±5 mm accuracy).
Shuttle Systems: Radio-frequency (RF) or rail-guided shuttles for lateral pallet transfer (2–10 pallet depths per lane).
Software & Control
WMS/WCS Compatibility: Real-time inventory tracking, route optimization, and predictive maintenance alerts.
Data Reporting: API integration for ERP systems, throughput analytics, and energy consumption monitoring.
Environmental Adaptability
Corrosion-resistant coatings for humid or chemically aggressive environments.
Cold chain optimization with frost-resistant lubricants and thermal insulation.
